Arduino Pro Micro 5V 16M Leonardo

45%
Arduino Pro Micro 5V 16M Leonardo
Arduino Pro Micro 5V 16M Leonardo - Image 2
Arduino Pro Micro 5V 16M Leonardo - Image 3
Arduino Pro Micro 5V 16M Leonardo - Image 4
  1. Arduino Pro Micro 5V 16M Leonardo
  2. Arduino Pro Micro 5V 16M Leonardo - Image 2
  3. Arduino Pro Micro 5V 16M Leonardo - Image 3
  4. Arduino Pro Micro 5V 16M Leonardo - Image 4
₹800.00 Original price was: ₹800.00.₹445.00Current price is: ₹445.00.
In Stock
Add to wishlist
In Stock
  1. ATMEGA32U4 running in 5V / 16MHz
  2. Support Arduino IDE V1.0.1
  3. Micro USB interface programming on the board
  4. Four 10-bit ADC pin
  5. 12 digital I / O (5 PWM capability)
  6. Rx and Tx hardware serial connection

This product has been added to 1 people'scarts.

  • Delivered today (order Mon-Fri before 12:00, delivery between 17:00 and 22:00)
  • Including shipping costs, sent by klbtheme.com
  • Pick up at a klbtheme.com collection point is possible
  • 30 days to change your mind and free returns
  • Day and night customer service
SKU: 26784
Categories: , ,

Description

The Arduino Pro Micro 5V 16M Leonardo has 4 channel 10 bit ADC, 5 PWM pins, 12 DIO, and a hardware serial connection Rx and Tx you are familiar with Running on 16MHz and 5V, this board will remind you a lot of other Arduino compatible boards that you like.

There is a voltage regulator on board, so it can accept up to 12V DC.

The Arduino Pro Micro 5V 16M Leonardo Micro is a microcontroller board based on the ATmega32U4. It has 20 digital input/output pins (of which 7 can be used as PWM outputs and 12 as analog inputs), a 16 MHz crystal oscillator, a micro USB connection, an ICSP header, and a reset button.

It contains everything needed to support the microcontroller; simply connect it to a computer with a micro USB cable to get started. It has a form factor that enables it to be easily placed on a breadboard.

The Micro board is similar to the Arduino Leonardo in that the ATmega32U4 has built-in USB communication, eliminating the need for a secondary processor.

This allows the Micro to appear to a connected computer as a mouse and keyboard, in addition to a virtual (CDC) serial / COM port.

If you supply an unstable power supply board, be sure to connect to the “RAW”, not on the VCC pin. It has also added a PTC fuse and diode protection to the power circuit and to correct the RX and LED TX circuits.

Technical Features :

  1. ATMEGA32U4 running in 5V / 16MHz
  2. Support Arduino IDE V1.0.1
  3. Micro USB interface programming on the board
  4. Four 10-bit ADC pin
  5. 12 digital I / O (5 PWM capability)
  6. Rx and Tx hardware serial connection.

Package Includes :

1 x Arduino Pro Micro 5V 16M Leonardo

[Order Now][More Info on Arduino Pro Micro 5V 16M Leonardo]
