PIR Motion Detector Sensor Module HC SR501

37%
PIR Motion Detector Sensor Module HC SR501
PIR Motion Detector Sensor Module HC SR501 - Image 2
PIR Motion Detector Sensor Module HC SR501 - Image 3
₹110.00 Original price was: ₹110.00.₹70.00Current price is: ₹70.00.
In Stock
Add to wishlist
In Stock
  1. Wide Working Voltage Range: DC 4.5V- 20V
  2. Current Drain: <60uA
  3. Detection Angle: <140°
  4. Detection Distance: 3 to 7m (can be adjusted)
  5. Blockade time: 2.5s (Default)
  6.  Work temperature: -20-+80°C
  7. Jumper for trigger.
  • Delivered today (order Mon-Fri before 12:00, delivery between 17:00 and 22:00)
  • Including shipping costs, sent by klbtheme.com
  • Pick up at a klbtheme.com collection point is possible
  • 30 days to change your mind and free returns
  • Day and night customer service
SKU: 54638
Categories: , , , , ,

Description

it is a PIR Motion Detector Sensor Module HC SR501. The PIR Motion Sensor Detector Module HC SR501 allows you to sense motion. It is almost always used to detect the motion of a human body within the sensor’s range. It is often referred to using “PIR”, “Pyroelectric”, “Passive Infrared” and “IR Motion” sensor.

The module has an onboard pyroelectric sensor, conditioning circuitry, and a dome-shaped Fresnel lens. It has a delay time adjustment Potentiometer and sensitivity adjustment Potentiometer. Compatible with ARDUINO, RASPBERRY PI, AVR, PIC, 8051, etc.
